Manejo de gabinetes – enclosures

https://www.youtube.com/watch?v=tmq2xScST3A

Producto Destacado: Rhino Tool House

Recientemente un cliente nuestro, Rhino Tool house, instaló…

Producto Destacado: Manipulador para Transferencia de Motor Diesel

En algunos casos, una grúa viajera o de riel patentado diseñada por Cynergy Ergonomics es el producto ideal para integrar un manipulador de alta capacidad
Force Sensing Handle Control

Producto Destacado: Maneral de Control Sensible a la Fuerza

Una opción muy versátil en el levante ergonómico es el maneral de control sensible a la fuerza que tiene prestaciones que ningún otro control puede igualar.

Burn Table/Plate Handling

A high speed servo drive, PLC controlled lifter incorporated with magnet based, pneumatically controlled end tooling is utilized to quickly and safely "sweep" the table - allowing the operators to lift and stack plates effortlessly.

Telescopic Mast Core Probe Roll Manipulator

Cynergy Ergonomics provides roll handling systems designed to pick the roll via the core in either the horizontal or vertical orientation and rotate 90 degrees. With the telescopic mast, the operator can travel over other palletized rolls or other obstructions.

Pallet Handling Vacuum Lift Assist

A vacuum lifter was installed into the work cell with adjustable cup end-tooling. This system provides for quick adjustment of cup spacing, allowing the operator to lift and stack the full range of pallets that are manufactured.

Welded Fabrications-Stress Relief Oven Manipulator Arm

Cynergy designed a free standing work cell crane system utilizing a rigid mast manipulator with gripper end tooling designed to pitch 90°.

Cross Frame Handling Chassis Assembly

A high speed servo drive, PLC controlled lifter incorporated with magnet-based, pneumatically controlled end tooling was installed into the work cell. The design enables the operators to pick from all layers of all dunnage racks and set into the weld fixture without bending, reaching or lifting the load.

Pharmaceutical Drum Dispensing, Lifting, Handling

Mobile, battery operated drum handling devices were provided designed to grasp individual drums, raise above hopper height and rotate, dispensing caplets as required into the individual hoppers.

Control Enclosure Assembly

Cynergy designed a lightweight, vacuum-based end tool coupled with a servo-drive lifter to lift and manipulate the various components. The servo-drive lifter provides high-speed maneuvering when desired as well as very slow, precise speed control when needed. In addition, “float mode” zero-gravity control was added to allow the operator to align the large, awkward load into position.

Distribution Center Manipulators

Rigid mast telescoping manipulators were provided through the center aisles between left hand and right hand pallet racks/feeder conveyors. The all-electric manipulators are extremely light and maneuverable allowing the operators to grab products of various sizes, weights, and construction, transfer them to a shipping pallet and build the regional order.

Engine Block Handling Lift Assist for Inspection on Machining Line

The problem was addressed by supplying a pneumatically operated below-the-hook tool designed to pick up the blocks from the conveyor, power rotate 180˚ and set on the inspection bench. This device also provided the added benefit of providing the operators with means of dumping the machine oil from the cylinder bores over a specified catch basin (which was previously being spilled on the test stand and operators).

Panel / Sheet Lifters Turning Cooler Counter Tops Lifting for Inspection and Assembly

A vacuum handling system was provided with a simple jib crane and hoist system. The panel lifters are designed to lift and pitch the panel, sheet or sheet metal to any desired position up to 180˚.

Manipulador de Llantas

Cynergy Ergonomics diseñó una levantador de alta velocidad para llantas que remplaza a un balancín neumático sin necesidad de modificaciones al montaje. Nuestro levantador tiene el mismo control de alta velocidad pero elimina los riesgos inherentes de los balancines.

Manipularor de Dirección Automotriz para carga de Contenedor

Requerimiento Un fabricante Tier 1 de direcciones automotrices…
